Network Operations Center along with NMS
The present network infrastructure design at Directorate General of Shipping (DGS) is dependent on the existing eGovernance System including ePariksha, eOffice, etc. projects. The network landscape details at DGS as follows:
The C-DAC Data Centre in Noida hosts various business applications for DGS, such as existing eGovernance System, ePariksha, BSID, Exit Exam, and eOffice. DGS is also availing Cloud Disaster Recovery Services from C-DAC.
Wide Area Network (WAN): MTNL 100 Mbps internet bandwidth available at DGS for business applications access from C-DAC Cloud Data Centre and internal usage purpose.
The Local Area Network (LAN) design considered in DGS is "Flat Switched Network (unmanaged)" with CAT6 Backbone without redundancy. The existing LAN infrastructure includes one Wireless Controller for managing 18 Wireless Access Points.
Indicative Current State Network Architecture
Indicative Future State Network Architecture
The following diagram shows the proposed Future State Network Infrastructure at DGS:
Objectives:
DGS intends to engage a Reputed Service Provider for:
- Providing Networking Equipment and Network Management System (NMS) with OEM Support Services
- Network Upgradation, Implementation & Configuration
- The Network Operations Center (NOC) will integrate with Enterprise Management Systems and SIEM Solutions
- Provide Real-time Monitoring through Video Wall Display
- Establish Single Pane of Glass for IT Incident Management
The scope includes Network Design, Hardware Provisioning, Installation, Configuration, Security Hardening, Maintenance, LAN/WAN Integration, Operational Support, Proactive Monitoring with Service Level Agreements (SLA).
